Suspended Concrete Flooring

Minimum Effort, Maximum Efficiency. No Compromise.

SPEEDFLOOR® Suspended Concrete Flooring is one of the lightest suspended concrete floor systems available in the market, incorporating a unique composite floor of steel and concrete, which makes light work of pouring anything from single-level, to multi-level structures. The galvanised steel joists are easy to assemble and light enough to be positioned by hand. There is no propping required - simply assemble the joists, add structural supports and you are ready to pour. Floors can typically achieve composite action in 72 hours. Manufactured from galvanised, high strength steel in a one pass roll-former, the frame is light enough to be manhandled into place for pouring. The ends are simply bolted to the joists which are then ready for transporting to site with no propping or painting required. Slabs can be 90mm to 220mm in thickness. Minimum compressive strength of 25mPa to achieve composite action is normally achieved within the first 72 hours of curing, depending on environmental conditions.

joistdrawing

Installation


Application

Concrete Beam Support


Masonry Wall Support


Internal Beam Support


Steel Angle
Support


Timber Wall
Support


Minimum Edge Support


Step in Slab


Set Down Angle inside Beam


Standard Shoe, Set Down, inside Beam,


Downloads

Standard Details

Screenshot 2025-07-28 at 12.07_edited.jpg

SPEEDFLOOR SCF Brochure

Deck Section (2)_edited_edited.jpg

SPEEDFLOOR SCF Manual

Deck Illustration_edited.jpg

Read More about Speedfloor SCF

Be Among the First.

2026 RSA Launch Registration
